Operation Section
151
DIAGNOSTIC TROUBLE CODE (DTC) CHART – SORTED BY DTC # (3 of 4)
Description
DTC Set 2
Description
DTC Set 2
SPN-2 FMI-2 SPN-2 FMI-2
DTC 1546: AUX analog Pull-Up/Down
3 low volta
g
e
520221 4 DTC 1662: PWM6 short to power 925 3
DTC 1547: AUX analog Pull-Up/Down
4 high voltage
713 3 DTC 1663: PWM7 open / ground short 926 5
DTC 1548: AUX analog Pull-Up/Down
4 low voltage
713 4 DTC 1664: PWM7 short to power 926 3
DTC 1551: AUX digital 1 high voltage 520222 3 DTC 1665: PWM8 open / ground short 2646 5
DTC 1552: AUX digital 1 low voltage 520222 4 DTC 1666: PWM8 short to power 2646 3
DTC 1553: AUX digital 2 high voltage 520223 3 DTC 1669: PWM9 open / ground short 2647 5
DTC 1554: AUX digital 2 low voltage 520223 4 DTC 1670: PWM9 short to power 2647 3
DTC 1555: AUX digital 3 high voltage 520224 3 DTC 2111: Unable to reach lower TPS 51 7
DTC 1555: Water Intrusion Detection 520224 3 DTC 2112: Unable to reach higher TPS 51 7
DTC 1556: AUX digital 3 low voltage 520224 4 DTC 2115: FPP1 higher than IVS 91 0
DTC 1561: AUX analog Pull-Down 2
high voltage
0 3 DTC 2116: FPP2 higher than IVS 29 0
DTC 1561: AUX analog Pull-Down 3
high voltage
0 3
DTC 2120: FPP1 invalid voltage and
FPP2 disagrees with IVS
520250 31
DTC 1561: AUX analog Pull-Down 2
low voltage
0 4
DTC 2121: FPP1-2 lower than
expected
91 18
DTC 1561: AUX analog Pull-Down 3
low voltage
0 4 DTC 2122: FPP1 voltage high 91 3
DTC 1611: Sensor supply voltage 1
and 2 out-of-range
1079 31 DTC 2123: FPP1 voltage low 91 4
DTC 1612: Microprocessor failure -
RTI 1
629 31
DTC 2125: FPP2 invalid voltage and
FPP1 disagrees with IVS
520250 31
DTC 1613: Microprocessor failure -
RTI 2
629 31
DTC 2126: FPP1-2 higher than
ex
p
ected
91 16
DTC 1614: Microprocessor failure -
RTI 3
629 31 DTC 2127: FPP2 voltage low 29 4
DTC 1615: Microprocessor failure -
A/D
629 31 DTC 2128: FPP2 voltage high 29 3
DTC 1616: Microprocessor failure -
Interrupt
629 31
DTC 2130: IVS stuck at-idle, FPP1/2
match
558 5
DTC 1621: RS-485 Rx inactive 0 31
DTC 2131: IVS stuck off-idle, FPP1/2
match
558 6
DTC 1622: RS-485 Rx noise 0 31
DTC 2135: TPS1/2 simultaneous
volta
g
es out-of-ran
g
e
51 31
DTC 1623: RS-485 Rx bad packet
format
0 31 DTC 2139: FPP1 lower than IVS 91 1
DTC 1624: RS-485 remote shutdown
request
0 31 DTC 2140: FPP2 lower than IVS 29 1
DTC 1625: J1939 shutdown request 1384 31 DTC 2229: BP pressure high 108 0
DTC 1626: CAN-J1939 Tx fault 639 12
DTC 2300: Spark coil 1 primary open or
short to ground
1268 5
DTC 1627: CAN-J1939 Rx fault 639 12 DTC 2301: Spark coil 1 primary shorted 1268 6
