Operation Section
152
Description
DTC Set 2
Description
DTC Set 2
SPN-2 FMI-2 SPN-2 FMI-2
DTC 1628: J1939 CAN address /
engine-number conflict
639 13
DTC 2303: Spark coil 2 primary open or
short to ground
1269 5
DTC 1629: J1939 TSC1 message
receipt loss
639 9 DTC 2304: Spark coil 2 primary shorted 1269 6
DTC 1630: J1939 ETC message
receipt loss
91 2
DTC 2306: Spark coil 3 primary open or
short to ground
1270 5
DTC 1632: PWM1-Gauge1 short to
ower
697 6 DTC 2307: Spark coil 3 primary shorted 1270 6
DTC 1633: PWM2-Gauge2 open /
ground short
698 5
DTC 2309: Spark coil 4 primary open or
short to ground
1271 5
DTC 1634: PWM2-Gauge2 short to
power
698 6 DTC 2310: Spark coil 4 primary shorted 1271 6
DTC 1635: PWM3-Gauge3 open /
ground short
699 5
DTC 2312: Spark coil 5 primary open or
short to ground
1272 5
DTC 1636: PWM3-Gauge3 short to
power
699 6 DTC 2313: Spark coil 5 primary shorted 1272 6
DTC 1637: PWM4 open / ground
short
700 5
DTC 2315: Spark coil 6 primary open or
short to ground
1273 5
DTC 1638: PWM4 short to power 700 6 DTC 2316: Spark coil 6 primary shorted 1273 6
DTC 1639: PWM5 open / ground
short
520230 5
DTC 2318: Spark coil 7 primary open or
short to ground
1274 5
DTC 1640: PWM5 short to power 520230 6 DTC 2319: Spark coil 7 primary shorted 1274 6
DTC 1641: Buzzer control ground
short
920 4
DTC 2321: Spark coil 8 primary open or
short to ground
1275 5
DTC 1642: Buzzer open 920 5 DTC 2322: Spark coil 8 primary shorted 1275 6
DTC 1643: Buzzer control short to
power
920 3
DTC 2324: Spark coil 9 primary open or
short to ground
1276 5
DTC 1644: MIL control ground short 1213 4 DTC 2325: Spark coil 9 primary shorted 1276 6
DTC 1645: MIL control short to power 1213 3
DTC 2327: Spark coil 10 primary open
or short to ground
1277 5
DTC 1651: J1939 ETC message
recei
t loss while in-
ear
91 9
DTC 2328: Spark coil 10 primary
shorted
1277 6
DTC 1661: PWM6 open / ground
short
925 5 DTC 2428: EGT temperature high 173 0
