Fault code Fault content Occurrence conditions
96. Air Inlet temperature
P0113 DFC_TCACDsSRCMax SRC High for boost temperature
P0112 DFC_TCACDsSRCMin SRC Low for boost temperature
P0113 DFC_TIntkVUsSRCMax SRC High for boost temperature
P0112 DFC_TIntkVUsSRCMin SRC Low for boost temperature
97. Engine ECU temperature
P0669 DFC_TECUPhysRngHi_0
Physical Range Check high for ECU temperature
sensor
P0668 DFC_TECUPhysRngLo_0
Physical Range Check low for ECU temperature
sensor
P0669 DFC_TECUSRCMax SRC high for ECU temperature sensor
P0668 DFC_TECUSRCMin SRC low for ECU temperature sensor
98. Throttle valve control.
P02E1 DFC_ThrVlvDrftOpn Throttle valve drift at open position
P02E1 DFC_ThrVlvGovDvtMax Positive governor deviation for throttle valve
P02E1 DFC_ThrVlvGovDvtMin Negative governor deviation for throttle valve
P02E0 DFC_ThrVlvHBrgOpnLd
Open load error for throttle valve powerstage
(H-bridge)
P02EB DFC_ThrVlvHBrgOvrTemp
Over temperature error for throttle valve
powerstage (H-bridge)
P02E3 DFC_ThrVlvHBrgShCirBatt1 Short circuit to battery on Out1 error for H-bridge
P02E3 DFC_ThrVlvHBrgShCirBatt2 Short circuit to battery on Out2 error for H-bridge
P02E2 DFC_ThrVlvHBrgShCirGnd1 Short circuit to ground on Out1 error for H-bridge
P02E2 DFC_ThrVlvHBrgShCirGnd2 Short circuit to ground on Out2 error for H-bridge
P02E5 DFC_ThrVlvJamVlvClsd Jammed valve of throttle valve
P02E4 DFC_ThrVlvJamVlvOpn Jammed valve of throttle valve
99. Throttle valve position sensor
P02E9 DFC_ThrVlvSRCMax Throttle valve position sensor voltage SRC high
P02E8 DFC_ThrVlvSRCMin Throttle valve position sensor voltage SRC low
100. DOC upstream temperature
P2080 DFC_TOxiCatUsPhysRngHi
Diagnostic Fault Check of DOC upstream
temperature for Physical Signal below minimum limit
P0546 DFC_TOxiCatUsSRCMax SRC high in Oxidation Catalyst upstream temperature
P0545 DFC_TOxiCatUsSRCMin SRC low in Oxidation Catalyst upstream temperature
101. DPF downstream temperature
P2033 DFC_TPFltDsSRCMax SRC high in Particle filter downstream temperature
P2032 DFC_TPFltDsSRCMin SRC low in Particle filter downstream temperature
102. DPF upstream temperature
P2084 DFC_TPFltUsPhysRngHi
Diagnostic Fault Check of DPF upstream
temperature for Physical Signal below minimum
limit
P242D DFC_TPFltUsSRCMax SRC high in Particle filter upstream temperature
P242C DFC_TPFltUsSRCMin SRC low in Particle filter upstream temperature
