Doosan DX225LC - Applicable Models; Safety Precautions

Cylinders
Page 11
SP000914
Reference
Number
Description
1 Tube Assembly
2 Bushing
3 Rod Assembly
4 Bushing
5Rod Cover
6 DD-Bushing
7 Retaining Ring
8 Buffer Seal
9U-Packing
10 Backup Ring
11 Dust Wiper
12 Retaining Ring
13 O-ring
14 Backup Ring
15 O-ring
16 Cushion Ring
17 Piston
18 Slipper Seal
19 Wear Ring
20 Ring
21 O-ring
22 Backup Ring
23 Piston Nut
24 Set Screw
25 Socket Head Bolt
26 Pipe Band Assembly
27 Hex Socket Bolt
28 Check Valve
29 Spring
30 Spring Support
31 Hex Socket Plug
32 Spring Washer
33 Hex Bolt
34 Pipe Assembly
35 Grease Nipple
Reference
Number
Description
