OPERATION and MAINTENANCE
MANUAL
COMPRESSOR MODEL
Doosan Infracore Portable Power
1293 Glenway Drive
Sta
tesville, N.C. 28625
DoosanPortablePower.com
P/N: 46673128 (03-2015) Rev A
P425WCU-EX-T2 (F66)
XP375WCU-EX-T2 (F65)
HP375WCU-EX-T2 (F67)
A PDF version of the Electronic Service
Manual is available for free download
on Doosan Passport>Doosan Portable
Power>Smart Equip Order Management
and Manuals

Table of Contents

Other manuals for Doosan P425WCU-EX-T2

Preview: Electronic Service Manual
Electronic Service Manual90 pages

Questions and Answers

  • M
    Matthew NovakAug 18, 2025
    Why won't my Doosan P425WCU-EX-T2 Air Compressor start?
    • S
      Samuel WatsonAug 18, 2025
      If your Doosan Air Compressor won’t start, several factors could be the cause. Check the battery condition and recharge if necessary, ensure the electrolyte level is adequate, and verify cable connections are clean and tight. Also, ensure that you have an adequate amount of clean fuel. Other potential issues include a blown fuse, which you should identify and replace. Addressing these should help resolve the issue.
  • M
    Mr. Eric DanielAug 21, 2025
    How to increase air delivery (CFM) on my Doosan P425WCU-EX-T2?
    • A
      Ashley RossAug 21, 2025
      If your Doosan Air Compressor has low air delivery, start by cleaning or replacing clogged air filter elements. Ensure the pressure regulation is correctly adjusted as per the manual. Inspect the inlet unloader/butterfly valve and make necessary adjustments. Also, check for and repair any compressed air leaks to ensure optimal performance.
  • D
    Debbie MillerAug 23, 2025
    What to do if my Doosan Air Compressor will not unload?
    • D
      David JeffersonAug 23, 2025
      If your Doosan Air Compressor will not unload, inspect the inlet unloader and make adjustments. Check the pressure regulator and regulation lines for leaks. Apply heat to lines and or orifice if there is ice in regulation lines and/or regulation orifice. Check operation of DC electric heaters, if equipped. Clean and/or replace the vent leak if it is plugged.
  • M
    Mrs. Kathleen WhiteAug 26, 2025
    Why did my Doosan P425WCU-EX-T2 Air Compressor stop unexpectedly?
    • D
      diane53Aug 26, 2025
      If your Doosan Air Compressor has stopped unexpectedly, several factors could be the cause. First, check if the compressor is out of fuel and add clean fuel if needed. Other potential issues include loose or broken belts, which should be tightened or replaced, and loose wire connections, which should be checked and repaired. Addressing these should help resolve the issue.
  • M
    Michelle MartinezAug 28, 2025
    What to do if my Doosan P425WCU-EX-T2 engine coolant temperature is too high?
    • A
      Antonio BradyAug 28, 2025
      If your Doosan Air Compressor's engine coolant temperature is too high, start by checking the coolant level and adding coolant if it's low. Also, inspect the belts for looseness or damage and tighten or replace them as needed. Ensure the compressor operates in a cooler environment and that the coolers are clean. Reposition the compressor to be more level if it's tilted beyond the operating limit.
  • A
    Amanda KellyAug 30, 2025
    How to fix low engine oil pressure on Doosan Air Compressor?
    • R
      rcarrAug 30, 2025
      If your Doosan Air Compressor shows low engine oil pressure, first check the oil level and add oil if it's low. Ensure the compressor is level. If the oil is old, change the engine oil, reviewing the engine oil specification to use the correct type. Replacing the engine oil filter can also help.
  • M
    Michael Jarvis MDSep 2, 2025
    Why is my Doosan Air Compressor vibrating excessively?
    • N
      nellisSep 2, 2025
      Excessive vibration in your Doosan Air Compressor can stem from several sources. Check the rubber mounting isolators for looseness or damage, and tighten or replace them as needed. Inspect the fan for defects or imbalance and replace if necessary. Also, a defective airend drive coupling can cause vibration, so consider replacing the coupling.
  • G
    George WestSep 4, 2025
    What causes the safety valve to open on a Doosan Air Compressor?
    • C
      Cory GarciaSep 4, 2025
      If the safety valve on your Doosan Air Compressor opens, it could be due to several reasons. First, reduce the pressure to the rated operating pressure if it's too high. Inspect the inlet unloader and make adjustments as needed. If the safety valve is defective, replace it. Also, check the pressure regulator and regulation lines for leaks. If there is ice in regulation lines and/or regulation orifice, apply heat to lines and/or orifice. Check operation of DC electric heaters, if equipped.
  • A
    amasonSep 7, 2025
    How to troubleshoot low engine speed on a Doosan Air Compressor?
    • E
      Elizabeth HicksSep 7, 2025
      If your Doosan Air Compressor has low engine speed, start by servicing the fuel filters. Drain and clean fuel tanks and add clean fuel. Reduce the pressure to the rated operating pressure if it's too high. Clean or replace air filter elements if they are clogged, and ensure the correct air filter elements are installed.
  • L
    lharrisonSep 9, 2025
    What causes low electrical system voltage in a Doosan Air Compressor?
    • D
      Darrell ThompsonSep 9, 2025
      If your Doosan Air Compressor has low electrical system voltage, check the belts for looseness or damage, and tighten or replace them as needed. Inspect the wires at switches and connectors for loose connections and repair them. Check the battery condition, recharge if necessary, check electrolyte level, add if necessary, and clean and tighten cable connections. Repair or replace the alternator if it is malfunctioning.

Summary

Foreword

Information

Proprietary nature of manual, warranty, scope, approved components, and intended uses of the compressor.

Safety Information

Safety Precautions

General safety warnings, operating conditions, fastener checks, and avoiding hazardous substances.

Compressed Air Hazards

Dangers of mishandling compressed air, pressure relief, breathing apparatus use, and hose safety.

Exhaust and Material Hazards

Hazards from hot exhaust, flammable materials, and potential hazardous substances used in the compressor.

Battery Safety

Hazards from battery acid and potential explosion, with precautions for handling.

Radiator Safety

Hazards from hot radiator coolant and steam, with precautions for handling.

Transport Safety

Safe loading, towing procedures, and checks for transporting the compressor.

Safety Decals

Explanation of safety decals (DANGER, WARNING, CAUTION, NOTICE) and their meanings.

General Data and Specifications

General Data Information

Specifications for compressor models, engine details, fluid capacities, temperature ranges, and weight measurements.

Expendable Service Parts List

List of service parts with their corresponding part numbers for maintenance and replacement.

Operating the Compressor

Control Panel Overview

Identifies and describes the functions of the control panel components like gauges and switches.

Quick View Screen Navigation

Explains how to navigate and view engine and compressor parameters displayed on the unit.

Fault and Alert Handling

Procedures for responding to and acknowledging system faults and alerts displayed on the unit.

Service Interval Management

How to view, acknowledge, and reset service intervals indicated by the system.

Display Setup and Configuration

Options for adjusting display intensity, contrast, and viewing mode for optimal visibility.

Compressor ID and Software Information

Procedures for managing compressor ID and accessing software version details and revision history.

Language and Unit Configuration

How to set the display language and measurement units (English/Metric).

Pre-Operation Setup and Towing

Steps for safe towing, setting up the unit on site, and preparing it for starting.

Starting and Shutdown Procedures

Detailed steps for safely starting the engine and compressor, and for shutting down the unit.

Pressure Regulator Adjustment

Instructions for adjusting the pressure regulator settings for optimal compressor performance.

Lubrication Guide

Compressor Oil Selection and Specification

Guidance on selecting the correct compressor oil based on operating pressure and ambient temperature.

Maintenance Procedures

General Maintenance and Safety

Importance of maintenance, safety during tasks, and general cleaning for optimal operation.

Scheduled Maintenance Tasks

Key maintenance tasks including oil level checks and air cleaner servicing at scheduled intervals.

System Component Checks

Inspection of gauges, fuel, battery, tires, and fasteners for proper condition and tightness.

Fluid System Inspection

Inspection and maintenance procedures for the radiator and hoses to ensure system integrity.

Filter and Cooler Servicing

Procedures for replacing compressor oil filters and cleaning the oil cooler for efficient operation.

Receiver Separator System Maintenance

Maintenance for the receiver separator, including oil draining and element replacement as per schedule.

Scavenge Line and Finish Care

Maintenance of the scavenge line and care instructions for the exterior paint finish.

Decal Replacement Procedure

Instructions for applying or replacing decals on the compressor enclosure to ensure safety compliance.

Troubleshooting Guide

Troubleshooting Introduction

Guidelines on approaching troubleshooting, identifying problems, and finding root causes.

Compressor Troubleshooting Chart

A chart listing common compressor complaints, their causes, and suggested corrections for quick resolution.

Diagnostic Codes Explained

Explanation of diagnostic codes displayed by the compressor and engine for error identification and resolution.

Revision History

A log of revisions made to the manual, indicating changes and updates over time.
