M Series Functions
Low Battery alarm Keypad Lockout Breaking In Alarm
The low battery indicator will
ash, an audible message is
heard when battery power is
getting low.
The lock will enter into a lockout
mode when a wrong user PIN
code is entered 3 times in a
row. Lockout mode lasts 15
minutes where the lock can be
operated with any credential
(except key pad).
Removing a battery and placing
it back will remove the lockout
mode.
An alarm will be activated
if someone is attempting to
remove the front escutcheon
from the door or force open the
door without valid use of inside
or outside lever.
Locking Status
Change (M5 only)
Key Override Alarm
The deadlatch on the mortise
part has a sensor which is
triggered when the door has
been opened without unlocking
the lock (pushing the outside
lever down). Example: breaking
the door frame, using an electrical
strike and frame-door distance
changes due to temperature
changes.
An alarm is heard every time
the key override is used.
It lasts for 30 seconds.
