Doro L30 Disassembly&Assembly procedure
9/17
3.8 Remove the 2.8 LCD and 1.77 LCD
Remove the back Camera from Flap B by using the forceps.
Disconnect LINK FPC.Remove ref Sub PCB from the Flap B by forceps.
.
Carefully separate the Flap B along the edge with a hard plastic plectrum or card.
Remove 2.8 LCD and 1.77 LCD from Sub PCB by using the forceps.
1.1 Assemble the LCD and back camera
