Doro L30 - Remove the 2.8 Lcd and 1.77 Lcd; Disassemble the Flapb

Doro L30 Disassembly&Assembly procedure
8/17
3.7 Disassemble the Flap B
Remove the Flap B from upper housing by using forceps to push in FLAP Hinge Unit carefully.
Not necessary unless the LCD Window needs to be replaced. Preheat (85℃) for about five minutes (hot
air gun/heating table) and carefully remove the LCD Window with a hard plastic plectrum/card.
Remove screws (qty=4) on the Flap B by screwdriver.
