Doro L30 - Remove the Receiver and Motor; Remove the Keypad and Speaker

Doro L30 Disassembly&Assembly procedure
10/17
3.9 Remove the receiver and motor
3.10 Remove the keypad and speaker
Remove the motor and receive from the front housing by using the forceps. Remove the LINK FPC from
the front housing.
Remove Speaker from ref lower housing by forceps.
Remove Keypad from the front housing.
