WILDEN PUMP & ENGINEERING, LLC 14 WIL-12350-E-02

St ep 21

After removing tubes inspect or replace the O-rings as needed.

Step 23

Remove the air chamber fasteners and gasket.

Step 24

Using a socket wrench, unbolt the power cylinder cover from the

center section.

AIR VALVE/CENTER-SECTION DISASSEMBLY

Step 22

Using the appropriate-sized wrench, remove the air chamber

fasteners.
