Dover markem imaje 9750 - Printer Overview; Printhead and Umbilical; Operator Interface; Printer Access and Power

1
2
3
75 6
4
8
9
10
11
2 10114437-AB
Printer overview
1 Printhead
2 Umbilical
3 Operator interface
4 Identification label (serial no.)
5 Umbilical outlet
6 Handle for opening the door
7 Access door for consumable parts and maintenance modules
8 Electrical socket
9 ON/OFF switch
10 Access to hydraulic/electric/electronic components
11 Identification label
see page 4
for parts & service call QLC (800) 837-1309
