3 10114437-AB
Printer overview
12
Additive cartridge
13
Ink cartridge
14
Internal USB port
15
Module 4 - Air in filter IP56 (violet)
16
Module 3 - Recovery pump/Venturi
17
Module 2 - Filter for the primary ink
18
Manual maintenance valve
19
Module 1 - Pressure pump
20
Module 5 - IP56 air out filter (violet) or non-removable IP66 filter (depending on the version)
21
Module 6 - Equipped hydraulic module
22
Standalone compressor kit module (optional)
23
Filter-silencer cartridge for the standalone compressor
24
Air Treatment Kit module (optional)
25
Filter cartridge for Air Treatment Kit module
