For all other probe types: enter the (normal) Density and NET (compensated) density values in the fields.
Enter the same value in both fields if one of the two values is not known.
6.3.4 Relays
The four internal relays of the console can be configured in this screen.
NOTE: The External Relays that show must first be set up in "Site Info" on pageî19.
The available alarms/actions that can be linked to a relay:
Disabled Low Very high Water
No Link Out of scale Very low Ethanol
High Probe Communication Not Initialized
Click Save when you complete the Relays configuration.
M2051-EU Rev.: 1 Dover Fueling Solutions
Page 35
