A11

Item Part Number Description Quantity

1 CL1010 LOCK SCREW 1

2 CL1007 KNIFE DISC LOCK ON 1

3 CL1005 DOOR LATCH 1

4 CL1012 UPPER HINGE PIN 1

5 CL1002 DOOR 1

6 CL1013 LOWER HINGE PIN 1

7 CL1003 PUSHER DOOR AND HANDLE 1

8 CL1018 ADJUSTEMENT SCREW FOR DOOR 1

9 CL1024 LOCK NUT 1

10 CL1023 TENSION SPRING 1

11 CL1022 KNIFE ADJUSTINGNUT FOR DISC 1

13 CL1571 HOLDER FOR CL6101K 1

14 CL1026 COLLER FOR DISC HOLDER 1

15 CL1026A SET SCREW FOR CL1026 1

16 CL1030 STUDS FOR DISC HOLDER 8

17 CL1008 NOSE FOR HOUSING HUB 1

18 CL1036 ROUND PIN 1

19 CL12K KNIFE 1

14,15,16,20 6107 DISC SUPPORT #12 ASSEMBLY 1

9,10,11,12,13,19 6101 DISC ASSEMBLY #12 1

21 6102 SHREDDER 3/32’’ 1

OR 6105 SHREDDER 3/16’’ 1

OR 6103 SHREDDER 1/4’’ 1

Model : VEGETABLE SLICER View : EXPLODE
