DPA 4099B - Polar Pattern

21
Power supply
Min. 5 V – max. 50 V through DPA adapter for wireless systems
48 V phantom power ±4 V with DAD4099 or DAD6001-BC XLR
adapter XLR adapter
Current consumption
Typ. 1.5 mA (microphone)
3.5 mA with DAD4099 or DAD6001-BC XLR adapter
Connector
MicroDot
Color
Black
Weight
4099B: 46 g (1.62 oz)
4099C: 38 g (1.34 oz)
4099D: 38 g (1.34 oz)
4099G: 36 g (1.27 oz)
4099P: 46 g (1.62 oz)
4099S: 31 g (1.1 oz)
4099T: 31 g (1.1 oz)
4099U: 41 g (1.4 oz)
4099V: 33 g (1.16 oz)
Capsule diameter
5.4 mm (0.2 in)
Polar Pattern
Directional characteristics of DPA 4099 (normalized)
250 Hz
500 Hz
8 kHz
16 kHz
4 kHz
2 kHz
1 kHz
5 dB
