The Dr. Mach LED 150F / 150 / 150FP is a medical lighting system designed to provide optimal illumination in various medical settings. This service manual outlines the key aspects of its function, usage, and maintenance, ensuring its safe and efficient operation.

Function Description:

The Dr. Mach LED 150F / 150 / 150FP is a sophisticated medical lighting device that utilizes LED technology to deliver high-quality illumination. Its primary function is to provide a bright, clear, and consistent light field, crucial for precise medical examinations and procedures. The LED technology ensures a long lifespan for the light source, reducing the need for frequent replacements and offering energy efficiency. The design of the light aims to minimize shadows and provide excellent color rendering, allowing medical professionals to accurately perceive tissue colors and details. The system is designed to be robust and reliable, meeting the stringent demands of medical environments. It operates with an external power supply, ensuring stable and safe electrical operation. The light is classified under Class I according to the Medical Device Regulation, indicating a high standard of safety and performance. The overall design focuses on delivering a dependable lighting solution that enhances visibility and supports accurate medical work.

Usage Features:

The Dr. Mach LED 150F / 150 / 150FP is designed for intuitive and user-friendly operation. Before initial use, it is crucial to store the light in the respective room for at least 24 hours to allow for temperature equalization, which helps prevent potential issues related to thermal stress. Users are advised to carefully read the instructions for use to maximize the lighting system's benefits and avoid any damage to the device. The light features a key pad for control, allowing for easy adjustment of its functions. The mobility of the light is a key feature, enabling medical professionals to position the light precisely where needed. This adjustability is critical for illuminating different areas of interest during procedures or examinations. The light's design ensures smooth movement, which can be adjusted to suit individual preferences for tightness or ease of movement in the light joint. This adaptability contributes to a comfortable and efficient working environment. The system requires a main control switch for power-off, which must meet specific electrical standards to ensure safety. The device is not designed for use in potentially explosive areas, and users must adhere to this safety guideline. Any modifications to the lamp are strictly prohibited to maintain its safety and performance integrity.

Maintenance Features:

Maintaining the Dr. Mach LED 150F / 150 / 150FP is essential for its longevity and continued optimal performance. The manual provides clear instructions for several key maintenance procedures. One common maintenance task is exchanging the protective glass. Over time, the protective glass can become dull or scratched, leading to a decrease in light efficiency. The manual details the step-by-step process for removing the old glass and installing a new one, emphasizing the correct positioning and the use of specific fixation screws. A torque wrench is recommended for tightening these screws to prevent damage to the glass or housing. Another important maintenance feature is the ability to exchange the key pad in case of malfunction. This involves disconnecting the light from mains, removing fixation screws, carefully detaching the old key pad, and installing a new one. The manual also addresses the adjustment of the light's mobility. If the light joint becomes too tight or too easy to move, it can be adjusted by accessing and manipulating a hexagonal nut. This procedure involves removing plastic caps, screws, and the upper part of the light to reach the adjustment mechanism. All repair and special assembly work must be carried out by authorized personnel or the manufacturer to ensure safety and compliance with regulations. It is critical to disconnect the entire system from mains before performing any dismounting or repair work to prevent damage to the electronic board. Regular checks to ensure the light is in perfect working order before every use are also recommended. The manual includes a comprehensive list of spare parts with their respective part numbers, facilitating easy ordering and replacement of components.

Dr. Mach 150F - Page 5
