Dr. Mach 150F - Spare Parts List

MACH LED 150F / 150 / 150FP
59593206 Service manual 06.02.2018; Edition 01 / Bar;Bak page 9
5. Spare parts
Item Qty. Name Part. no. Remarks
1 7 Fixation screw for protective glass 65872004
2 1 Protective glass 32035201
3 2 Fixation screw for key pad 65112003
4 1 Key pad LED 150 14117002
5 2 Plastic caps for the upper housing part 32032304
6 2
Fixation screw for upper housing part,
upper side and bottom side
65852004
7 6
8 1 Upper housing part 32032302
9 1 Adjusting nut for the mobility setting 67900002
Subject to change without notice due to technical modification
