MACH LED 150F / 150 / 150FP
59593206 Service manual 06.02.2018; Edition 01 / Bar;Bak page 7
4. Adjusting the mobility of the light
Failure description: In case of tight-running or easy movement of the light, the mobility in the
light joint can be adjusted.
 Turn off the light.
 Remove the two plastic caps (pos. 5) with an appropriate tool (e.g. flat screw driver) and
loosen and remove the screws (pos. 6).
 Remove the protective glass, as described in chapter 2.
 Loosen and remove the six marked screws (pos. 7).
5
6
7
