MACH LED 150F / 150 / 150FP
59593206 Service manual 06.02.2018; Edition 01 / Bar;Bak page 8
 Remove the upper part of the light (pos. 8).
 Use a fork spanner (width 19) to adjust the hexagonal nut M12x1 (pos.9) by loosening or
tightening, until the requested mobility of the light has been reached.
The assembly of the light is done in reverse order.
8
7
9
