SELF-FEEDING CHIPPER
Parts List - Chipper Basic Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 37770 Sideplate Weldment, Chute (16.5)
37771 Sideplate Weldment, Chute (21.0)
2 37425 Scroll Weldment, (16.5)
37426 Scroll Weldment, (21.0)
3 37421 Sideplate Weldment, Vent
37422 Sideplate Weldment, Vent, (21.0)
4 24197 Bolt, HCS, 5/16-18 x 4-1/2, Gr5
5 37500 Nut, Lock, 5/16-18, Gripco
6 37405 Tube, Scroll, (16.5)
37406 Tube, Scroll, (21.0)
7 37431 Flywheel, Balanced w/Knife, (16.5)
37432 Flywheel, Balanced w/ Knife, (21.0)
8 24242 Bearing, Flange, 1-1/4" Shaft
9* 24246 Shim, Shaft, 1/-1/4, .125 Thk
24245 Shim, Shaft, 1/-1/4, .075 Thk
24244 Shim, Shaft, 1/-1/4, .050 Thk
24243 Shim, Shaft, 1/-1/4, .025 Thk
10 24247 Ring, Retaining, 1-1/4 Shaft
Ref# Part# Description
11 24248 Bolt, HCS, 1/2-13 x 1-1/2, Gr5
12 37501 Nut, Lock, 1/2-13, Gripco
13 37407 Plate, Wear, (16.5)
37408 Plate, Wear, (21.0)
14 19566 Bolt, Carriage, 1/4-20 x 1
15 14339 Washer, Flat, 1/4
16 14340 Nut, Nylon Lock, 1/4-20
17 37401 Plate, Access, 3 Hole, (16.5)
37402 Plate, Access, 3 Hole, (21.0)
18 37399 Plate, Access, 2 Hole, (16.5)
37400 Plate, Access, 2 Hole, (21.0)
Not Shown
38049 Knife Kit, (16.5)
38050 Knife Kit, (21.0)
34141 Label, DR Logo, Silver, 5.75"
24200 Label, Warning, Rotating Knife
24199 Label, Danger, Rotating Parts Inside
