DR Field Parts Manual

44 DR
®
FIELD and BRUSH MOWER
Parts List - Frame and Drive Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 150261 Frame, Main
02 192901 Engine, 11.5HP, B & S, e/s
192921 Engine, 13HP, B & S, e/s
160191 Engine, 15HP, Kawasaki, e/s
160881 Engine, 17HP, Kawasaki, e/s
03 134431 Bolt, HCS, 5/16"- 18 x 1-1/2", GR 5
04 111411 Bolt, HCS, 5/16"- 18 x 3", GR 5
05 150451 Bolt, HCS, 5/16"- 18 x 1-3/4", GR 5
06 110761 Nut, Nylon Lock, 5/16"- 18
07 110691 Nut, 5/16"- 18
08 112501 Washer, Lock, 5/16" External Tooth
09 112311 Spacer, .327" ID x .50" OD x 1.5" L
10 191261 Bracket, Anti-Rotation
11 150611 Idler Arm, Traction Drive
12 110751 Nut, Nylon Lock, 3/8"- 16
13 112391 Washer, Flat, 3/8” (USS)
14 151111 Bushing, .390" ID x .62" OD x 1.585" L
15 164841 Bolt, HCS, 3/8"- 16 x 2-1/2", GR 5
16 108501 Pulley, Flat, Idler, 3.0" OD
17 157121 Bolt, HCS, 3/8"- 16 x 2-1/4", GR 5
18 175521 Eyebolt, 10 - 24 x 1/2"
19 118731 Nut, Nylon Lock, 10 - 24
20 150501 Spring, Extension, .438" OD x 2.5" FL
21 191211 Pulley, Drive, 2-3/4" Dia., 1" Bore
22 191281 Key, 1/4" Square x 2-1/4" L
23 191241 Clutch, Electric, 75 Ft.-Lbs., 3.86 Amp
24 191141 Bolt, HCS, 7/16"- 20 x 2-1/2", GR 5
25 151321 Washer, Lock, 7/16" Split
26 191301 Washer, Flat, .469" ID x 1.62" OD
27 150201 Guide, Belt, Engine Pulley
28 119831 Bolt, HCS, 1/4"- 20 x 3/4"
29 112481 Washer, Lock, 1/4" External Tooth
30 112381 Washer, Flat, 1/4" USS
31 150061 Belt, A31K, 1/2" x 33"
32 111141 Pulley, V-Belt, 7" OD, 5/8" Bore
33 111241 Ring, Retaining, 5/8", Type SH
34 101451 Bolt, 1/4"- 20 x 1-1/2"
35 111871 Spacer, 1/4" ID, 3/8" OD, 1.0" L
36 112371 Washer, Flat, 10 - 24 USS
37 191171 Wire Harness, Kawasaki, E/S
191181 Wire Harness, B & S, E/S
38 150141 Cable, Ground, 16"
39 110731 Nut, Nylon Lock, 1/4"- 20
40 150591 Transmission, 4FWD, 1REV, w/Brake
Ref# Part# Description
41 123211 Bolt, HCS, 5/16"- 18 x 3/4", GR 5
42 151001 Arm, Transmission Shift
43 150771 Nut, Nylon Lock, 3/8"- 24
44 160331 Tie Rod, 7.47" L, Rod & Ball Ends
45 123361 Bolt, HCS, 5/16"- 18 x 1-1/4", GR 5
46 181131 Cable, Transmission, Brake
47 110701 Nut, 1/4"- 20
48 111491 Bolt, HCS, 1/4"- 20 x 1", GR 5
49 150171 Support, Chain Idler
50 111731 Screw, 5/16"- 18 x 1/2", Tri-Lobe
51 112431 Washer, Lock, 5/16", Split
52 151941 Bracket, Clutch, Cable Guide
53 150101 Bushing, .328" ID, .500" OD, 2.32" L
54 164781 Idler Arm, Inner, Chain Adjust
55 164771 Idler Arm, Outer, Chain Adjust
56 150481 Pulley, Flat Idler, 1.88" OD, .375" Bore
57 126861 Bolt, HCS, 3/8" - 16 x 2", GR 5
58 164801 Spring, Extension, .750" OD x 3" FL
59 150181 Guard, Chain
60 187551 Nut, Nylon Lock, 5/16"- 18, Lo-Profile
61 150411 Mount, Fuel Tank
62 114701 Bolt, HCS, 1/4"- 20 x 1/2"
63 150291 Fuel Tank Assembly, 2.5 Gallons
64 150531 Strap, 2.5 Gallon Fuel Tank
65 150241 Debris Guard
66 151381 Washer, 1.375" ID, 2.00" OD x .25"
67 151151 Washer, 1.38" ID, 2.00" OD, for Pin
68 150461 Pin, Detent, 1/4" x 2"
Not Illustrated:
Ref# Part# Description
123451 Hose, Fuel, 1/4" ID
100661 Clamp, Fuel Line
130381 Elbow, Oil Drain, B & S only
130401 Nipple, Oil Drain, B & S only
140021 Tubing, Oil Drain, Kawasaki only
100941 Fuel Filter, B & S
138741 Fuel Filter, Kawasaki
