46 DR
®
FIELD and BRUSH MOWER
Parts List - Brush Deck Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 164561 Brush Deck, 26
160621 Brush Deck, 30"
02 150911 Spindle Housing, Brush Deck
03 150721 Bushing, 1.38" ID x 1.63" OD x 1.5"
04 160091 Shaft, Spindle, w/Bearing
05 187351 Bearing, Ball 2 Seals
06 151141 Hub, Spindle, Brush Deck
07 100481 Blade, 26" Air Tip
160891 Blade, 30” Air Tip
08 101771 Washer, .640" ID x 2.5" OD x .38", Blade
09 160071 Nut, Nylon Lock, 5/8"- 18
10 164451 Pulley, V-Belt, 8.5" OD
11 150681 Belt, B63K, 5/8" x 66"
12 150641 Anti-Wrap Guard, 4 Hole Mount
13 110751 Nut, Nylon Lock, 3/8"- 16
14 111521 Bolt, HCS, 3/8"- 16 x 1", GR 5
15 160511 Baffle, 26"
160611 Baffle, 30"
16 123211 Bolt, HCS, 5/16"- 18 x 3/4", GR 5
17 110761 Nut, Nylon Lock, 5/16"- 18
18 145291 Bolt, Carriage, 5/16"- 18 x 3/4"
19 150831 Idler Arm, Brush Deck
20 150691 Bolt, HCS, 3/8"- 16 x 2-1/2", GR 5
21 112391 Washer, Flat, 3/8" USS
22 151271 Pulley, Flat Idler, 4", 3/8" Bore
23 150941 Spring, Extension, 3/4" OD x 5.0" L
24 150701 Bolt, HCS, 3/8"- 16 x 3-3/4", GR 5
25 150711 Bushing, Idler, .386" ID x .625" OD x 2.78"
26 164401 Lever, Belt Tension Release
27 165231 Bracket, Belt Tension Lever
28 112411 Washer, Flat, 5/16" USS
29 157271 Cover, Deck Drive Belt w/Label
30 143661 Knob, 5/16"- 18 Hole
31 101891 Zerk, Grease Fitting, 1/4"- 28, Straight
32 164371 Label, Belt Routing (not shown)
