6 DR
®
PILOT 2 Cycle Tiller/Cultivator
Chapter 2: Setting up your DR PILOT 2 Cycle Tiller/Cultivator
This chapter outlines a few simple steps you will need to follow to set up your new machine before you use it. It may be
helpful to familiarize yourself with the controls and features on your new machine by reviewing Figure 1 on the following page
before beginning the steps outlined in this chapter. For technical assistance, please visit our website at www.DRpower.com
and one of our Technical Support Representatives will be happy to help you.
DR PILOT 2 Cycle Tiller/Cultivator Specification Sheet
Engine 2-Cycle, 43cc, Manual Start
Fuel Tank Capacity 36 ounces
Fuel Type Minimum 87 octane gasoline.
NOTE: If using an ethanol
blended fuel, a fuel
stabilizer, mixed to manufacturer
specifications,
is recommended.
Oil/Gas Ratio 50:1 (2.6 ounces per gallon)
Oil Type 2-Cycle Engine Oil
Spark Plug Torch
L7RTC or Champion RCJ6Y
Spark Plug Gap .027"
Transmission
Bronze gear drive
Gear Ratio 32:1
Tilling Width 6" minimum to 10" maximum
Tilling Depth 8" max
Tine Speed 250 RPM max
Wheel Size 1.375 x 7.0" diameter
Machine Weight 33 lbs.
Machine Size 35"L x 18"W x 38"H
