20 DR

PILOT 2 Cycle Tiller/Cultivator

Chapter 6: Parts Lists and Schematic Diagrams

Parts List - Handlebar Assembly

NOTE: Part numbers listed are available through DR Power Equipment.

Ref# Part# Description

1 26161 Bolt 10-24 X 1-1/4 Phillips

2 39902 Handlebar Upper Right

3 25196 Throttle Cable

4 39903 Rubber Pad

5 39904 Trigger Assembly Short Throw

6 26144 Handlebar Grip

7 39905 Handlebar Upper Left

8 25729 T-Handle Nut

9 26146 Curved Washer

10 26147 Saddle Bolt

11 26159 Handlebar Middle

12 39906 Handlebar Parts Packet

13 39907 Manual Parts Bag
