READ AND UNDERSTAND THIS MANUAL AND ALL INSTRUCTIONS
BEFORE OPERATING THIS TILLER.
DR
®
ROTO-HOG™ POWER TILLER
SAFETY & OPERATING INSTRUCTIONS

Table of Contents

Questions and Answers:

DR ROTO-HOGTM Specifications

General IconGeneral
EngineBriggs & Stratton 8.75 FPT, 206 CC, Single Cylinder
Approximate Run Time on a Tank of Fuel90 minutes
Range7" to 2"
Actuator Stroke3.94"
Actuator Maximum Load250 lbs.
Battery12 Volt, 17AH
# of Cycles for Fully Charged Battery400
Towing typePin Hitch
Ground Clearance in Transport Mode2.75"
Height AdjustmentElectric Actuator
Length of Remote Control Cable46"
Tine Size12"
Number of Tines24
Wheels15" x 6.00"-6 NHS (14" x 5.5")
Gauge of Steel on Shroud13
Gauge of Steel on Frame12 Gauge, 1.5" Tubular Steel
Weight and Dimensions IconWeight and Dimensions
Machine Size39"w x 66"L (Transport), 35"H x 77"L (Lowest Position)
Machine Weight259 lbs. Manual Start, 264 lbs. Electric Start
Tongue Weight90 lbs. (Transport) 112 lbs. (Lowest Position)
Shipping Weight310 lbs. Manual Start, 320 lbs. Electric Start

Summary

General Safety Rules

Protecting Yourself and Those Around You

Details essential personal protective equipment and safe operating practices to prevent injury.

Slope Operation

Outlines critical precautions and limitations for operating the tiller on sloped terrain.

Safety for Children

Provides guidelines to ensure children's safety around the operating tiller.

Safety with Gasoline-Powered Machines

Covers hazards associated with gasoline and safe handling and engine operation practices.

General Safety

Offers general operating precautions and responsibilities for safe tiller use.

Setting Up Your DR ROTO-HOG POWER TILLER

Unpacking and Assembling the Machine

Provides step-by-step instructions for safely removing and assembling the tiller from its packaging.

Operating Your DR ROTO-HOG POWER TILLER

Before Starting the Engine

Lists essential checks and preparations required before starting the tiller's engine.

Operating Safety

Emphasizes critical safety guidelines and precautions for operating the tiller.

Slopes and Uneven Terrain

Details safety precautions and limitations when operating on slopes or uneven ground.

Maintaining the DR ROTO-HOG POWER TILLER

Regular Maintenance Checklist

Provides a checklist of regular maintenance tasks and their recommended intervals.

Troubleshooting

Troubleshooting Table

A table listing common problems, their possible causes, and solutions for the tiller.

Parts Lists, Schematic Diagrams and Warranty

2-Year Limited Warranty

Outlines the terms, conditions, and duration of the product's limited warranty.

Terms and Conditions

Details the specific terms, limitations, and responsibilities covered by the warranty.
