28 DR
®
ROTO-HOG™ POWER TILLER
Slopes and Uneven Terrain
NEVER OPERATE YOUR DR ROTO-HOG POWER TILLER ON SLOPES GREATER THAN 5 DEGREES.
DOING SO COULD RESULT IN SERIOUS INJURY OR DAMAGE TO YOUR MACHINE.
WHEN OPERATING THE MACHINE OVER UNEVEN TERRAIN AND SLOPES, USE EXTREME CAUTION TO
NOT TIP OVER THE MACHINE. MOVE SLOWLY IF THE GROUND HAS RUTS, BUMPS, AND OTHER
DEPRESSIONS.
Handling and Transporting
NEVER LIFT THE MACHINE WHILE THE ENGINE IS RUNNING.
We recommend using two (2) people to lift the DR ROTO-HOG POWER TILLER. Lift the machine by the
SMOOTH-TRAK™ Hitch to connect and disconnect from your Tow Vehicle. To transport the machine with
your Tow Vehicle, first raise the tines to the MAX position (lower the Wheels) using the Control Box.
THE DR ROTO-HOG POWER TILLER IS NOT EQUIPPED FOR TOWING ON ANY PUBLIC ROADWAY.
WHEN TOWED, THE MAXIMUM SAFE TOWING SPEED IS 10 MPH.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the DR ROTO-HOGTM and is the answer not in the manual?

DR ROTO-HOGTM Specifications

General IconGeneral
EngineBriggs & Stratton 8.75 FPT, 206 CC, Single Cylinder
Approximate Run Time on a Tank of Fuel90 minutes
Range7" to 2"
Actuator Stroke3.94"
Actuator Maximum Load250 lbs.
Battery12 Volt, 17AH
# of Cycles for Fully Charged Battery400
Towing typePin Hitch
Ground Clearance in Transport Mode2.75"
Height AdjustmentElectric Actuator
Length of Remote Control Cable46"
Tine Size12"
Number of Tines24
Wheels15" x 6.00"-6 NHS (14" x 5.5")
Gauge of Steel on Shroud13
Gauge of Steel on Frame12 Gauge, 1.5" Tubular Steel
Weight and Dimensions IconWeight and Dimensions
Machine Size39"w x 66"L (Transport), 35"H x 77"L (Lowest Position)
Machine Weight259 lbs. Manual Start, 264 lbs. Electric Start
Tongue Weight90 lbs. (Transport) 112 lbs. (Lowest Position)
Shipping Weight310 lbs. Manual Start, 320 lbs. Electric Start
