DR ROTO-HOGTM User Manual

42 DR
®
ROTO-HOG™ POWER TILLER
Parts List -Tine Drive Transmission Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 233401 Washer, Felt, .985" x 1.515"
02 231381 Cap
03 233161 Nut, Hex, 5/16"-18, Flanged Lock
04 233231 Assembly, Flange & Bearing
05 233391 Gasket, Flange
06 233531 Assembly, Drive Housing, Side, LH
07 233491 Gasket, Drive Housing
08 233431 Plug, Oil
09 233511 Cap, Bearing
10 233501 Bearing, Roller
11 233051 Nut, Hex, 1/4"-20 w/Lock Washer
12 233251 Assembly, Tine Shaft & Sprocket
13 233451 Chain, Roller (Short)
14 233441 Assembly, Idler Shaft
15 233461 Assembly, Input Shaft
16 233541 Seal
17 233411 Chain, Roller (Long)
18 233521 Assembly, Drive Housing, Side, RH
19 233471 Bracket, Belt Guard & Idler
20 231421 Bolt, Hex, 1/4"-20 x 5/8" w/Washer
21 233421 Washer, Thrus,t .64" x .9375"
22 231371 Tine Assy, RH
23 26148 Tine Assy, LH

DR ROTO-HOGTM Specifications

General

Engine	Briggs & Stratton 8.75 FPT, 206 CC, Single Cylinder
Approximate Run Time on a Tank of Fuel	90 minutes
Range	7" to 2"
Actuator Stroke	3.94"
Actuator Maximum Load	250 lbs.
Battery	12 Volt, 17AH
# of Cycles for Fully Charged Battery	400
Towing type	Pin Hitch
Ground Clearance in Transport Mode	2.75"
Height Adjustment	Electric Actuator
Length of Remote Control Cable	46"
Tine Size	12"
Number of Tines	24
Wheels	15" x 6.00"-6 NHS (14" x 5.5")
Gauge of Steel on Shroud	13
Gauge of Steel on Frame	12 Gauge, 1.5" Tubular Steel

Weight and Dimensions

Machine Size	39"w x 66"L (Transport), 35"H x 77"L (Lowest Position)
Machine Weight	259 lbs. Manual Start, 264 lbs. Electric Start
Tongue Weight	90 lbs. (Transport) 112 lbs. (Lowest Position)
Shipping Weight	310 lbs. Manual Start, 320 lbs. Electric Start
