40 DR
®
ROTO-HOG™ POWER TILLER
CHAPTER 7
PARTS LISTS, SCHEMATIC DIAGRAMS AND WARRANTY
Parts List - Main Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 232971 Pin, Channel Pivot 1/2"
02 232891 Washer, 1/4" Std .312" x .734"
03 233071 Bolt, Hex 5/16"-18 x 3/4" Self
04 231251 Fender
05 232921 Bolt, Hex 5/16"-18 x 2-1/4", G5
06 232991 Bolt, Hex 5/16"-18 x 3-1/2", G5
07 233091 Bolt, Hex 5/8"-11 x 7-1/2", G5
08 231221 Chassis, RH
09 231211 Chassis, LH
10 231391 Spacer
11 233311 Nut, Hex, Nylock, 5/8"-11
12 231311 Brace, Front Case
13 231291 Angle, Reinforcement
14 233081 Nut, Hex, Nylock, 5/16"-18
15 232941 Bolt, Hex, 1/4"-20 x 1", G5
16 231281 Cap, Fender End, LH
17 231271 Cap, Fender End. RH
18 231301 Brace, Rear Case
19 233301 Nut, Jam, Hex, 5/16"-24
20 233041 Nut, Hex 1/4"-20 w/Lock Washer
21 233591 Pin, Hair, 1/8" x 1-5/8"
22 233351 Pin, Clevis, 3/8" x 1-3/4"
23 233621 Pin, Clevis, 1/2" x 2"
24 233011 Pin, Hair, .08" x 1.58"
25 233211 Assembly, Fender Tube
26 233241 Transmission
27 231261 Tube, Frame
28 232961 Bolt, Hex, 5/16"-18 x 2-1/2"
29 233281 Bolt, Hex, 1/4"-20 x 1-1/4", G5
30 232561 Actuator
31 233321 Pin, Hair, 5/32" x 3"
32 233181 Assembly, Tongue
33 233001 Pin, Clevis, 3/8" x 4"
34 232861 Nut, Hex, 5/16"-18, Lock, 3-Way
35 233201 Assembly, Hitch Bracket
36 232951 Washer, #10
37 232660 Clutch Lever
Ref# Part# Description
38 233381 Screw, 5/16"-18 x 5/16"
39 233551 Pulley, 4.5" OD
40 233361 Key, 3/16" x 1-3/4"
41 233111 Rod, Guide, V-Belt
42 233061 Bolt, Hex, 5/16"-24 x 1" w/Lock
43 232871 Washer, 5/16" Std .375 x .875
44 231231 Rod, Clutch
45 231331 Bracket, Idler Arm
46 233561 Bolt, Shoulder, 3/8"-16 x 7/8" W
47 233611 Switch, Interlock
48 233371 Pulley, Idler, 2-3/4"
49 233131 Rivet, Pop
50 232821 Bolt, Hex, 3/8"-16 x 1-3/4", G5
51 233121 Screw, Washer Head, 1/4"-20 x 1/2"
52 224290 Belt Cover, Universal
53 232720 Spring, Extension
54 233581 Key, Woodruff, #61
55 233481 Ring, Retaining
56 217630 V-Belt, 45"
57 233571 Pulley, 8" OD
58.1 231241 Cover, Drive, (Electric Start)
58.2 231341 Cover, Drive, (Manual Start)
59 231351 Guard, Foot
60 233261 Engine, B&S 8.75 (Manual Start)
233271 Engine, B&S 8.75 (Electric Start)
61 233601 Nut, Hex, Nylock, 3/8"-16
62 232911 Nut, Hex, 1/4"-20
63 233031 Nut, Hex, Nylock, 1/4"-20
64 232851 Bolt, Hex, 5/16"-18 x 1", G5
65 231461 Plug, Threaded Pipe
66 232931 Bolt, Slotted, #10-32 x 5/8"
67 233021 Nut, Nylock, #10-32
68 231481 Screw, Round, #8-32 x 5/8"
69 232791 Nut, Nylon, #8-32
70 231451 Tie, Nylon
71 233171 Module
72 232841 Bolt, Hex, 1/4"-20 x 3/4", G5

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the DR ROTO-HOGTM and is the answer not in the manual?

DR ROTO-HOGTM Specifications

General IconGeneral
EngineBriggs & Stratton 8.75 FPT, 206 CC, Single Cylinder
Approximate Run Time on a Tank of Fuel90 minutes
Range7" to 2"
Actuator Stroke3.94"
Actuator Maximum Load250 lbs.
Battery12 Volt, 17AH
# of Cycles for Fully Charged Battery400
Towing typePin Hitch
Ground Clearance in Transport Mode2.75"
Height AdjustmentElectric Actuator
Length of Remote Control Cable46"
Tine Size12"
Number of Tines24
Wheels15" x 6.00"-6 NHS (14" x 5.5")
Gauge of Steel on Shroud13
Gauge of Steel on Frame12 Gauge, 1.5" Tubular Steel
Weight and Dimensions IconWeight and Dimensions
Machine Size39"w x 66"L (Transport), 35"H x 77"L (Lowest Position)
Machine Weight259 lbs. Manual Start, 264 lbs. Electric Start
Tongue Weight90 lbs. (Transport) 112 lbs. (Lowest Position)
Shipping Weight310 lbs. Manual Start, 320 lbs. Electric Start
