DR ROTO-HOGTM User Manual

CALL TOLL FREE 1-800-DR-OWNER 31
Removing and Replacing the Engine Oil
WHEN PERFORMING ANY MAINTENANCE, YOU MUST FIRST SHUT OFF THE ENGINE, WAIT FIVE (5)
MINUTES TO ALLOW PARTS TO COOL AND DISCONNECT THE SPARK PLUG WIRE, KEEPING IT AWAY
FROM THE SPARK PLUG.
BE CERTAIN TO FILL THE ENGINE WITH OIL BEFORE STARTING. SEE PAGE 18.
Tools & Supplies Recommended:
• Flat Head Screw Driver
• Vacuum Pump Oil Drainer
• SAE 30 High Detergent, 20 oz. (0.60L)
NOTE: Remove the oil when the engine is warm. Warm oil flows quickly and completely.
1. Using a Flat Head Screw Driver, remove the Oil Fill Cap and vacuum the oil from the Engine through
the Oil Fill (Figure 10 on page 19) using a Vacuum Pump Oil Drainer.
2. Replace the oil by following the instructions on page 18.
NOTE: Use SAE 30 High Detergent oil classified “For Service SF, SG, SH, SJ” or higher. Do not use special
additives. Other types of oil could cause problems operating your machine. Please refer to your Engine
Owner’s Manual for detailed oil information.
3. Reattach the Spark Plug wire.
NOTE: Be sure to use environmentally safe disposal procedures for the used oil.

DR ROTO-HOGTM Specifications

General

Engine	Briggs & Stratton 8.75 FPT, 206 CC, Single Cylinder
Approximate Run Time on a Tank of Fuel	90 minutes
Range	7" to 2"
Actuator Stroke	3.94"
Actuator Maximum Load	250 lbs.
Battery	12 Volt, 17AH
# of Cycles for Fully Charged Battery	400
Towing type	Pin Hitch
Ground Clearance in Transport Mode	2.75"
Height Adjustment	Electric Actuator
Length of Remote Control Cable	46"
Tine Size	12"
Number of Tines	24
Wheels	15" x 6.00"-6 NHS (14" x 5.5")
Gauge of Steel on Shroud	13
Gauge of Steel on Frame	12 Gauge, 1.5" Tubular Steel

Weight and Dimensions

Machine Size	39"w x 66"L (Transport), 35"H x 77"L (Lowest Position)
Machine Weight	259 lbs. Manual Start, 264 lbs. Electric Start
Tongue Weight	90 lbs. (Transport) 112 lbs. (Lowest Position)
Shipping Weight	310 lbs. Manual Start, 320 lbs. Electric Start
