18 DR

PILOT 4 Cycle Tiller/Cultivator

Chapter 6: Parts Lists and Schematic Diagrams

Parts List - Handlebar Assembly

NOTE: Part numbers listed are available through DR Power Equipment.

Ref# Part# Description

1 35919 Upper Left Handlebar Assembly Grey

2 35920 Upper Right Handlebar Assembly Grey

3 35921 Knob Textured Handle Grip

4 25729 T-Handle Nut

5 26146 Washer

6 26147 Handle Clamp Bolt

7 35922 Middle Handlebar Assembly Grey

8 26161 Bolt 10-24 X 1 1/4

9 35923 Handlebar Rubber Pad 15mm X 28.5mm

10 26162 Trigger Assembly Long

11 35924 On/Off Switch Wire Assy

12 25196 Throttle Cable

13 35925 Nut M6 X 1.0

14 35926 Curved Washer M6

15 35927 Eyebolt M6 X 12 X 25

16 35928 Throttle Trigger Kit With Cable
