DR PILOT 4 User Manual

6 DR
®
PILOT 4 Cycle Tiller/Cultivator
Chapter 2: Setting up your DR PILOT 4 Cycle Tiller/Cultivator
This chapter outlines a few simple steps you will need to follow to set up your new machine before you use it. It may be
helpful to familiarize yourself with the controls and features on your new machine by reviewing Figure 1 on the following page
before beginning the steps outlined in this chapter. For technical assistance, please visit our website at www.DRpower.com
and one of our Technical Support Representatives will be happy to help you.
DR PILOT 4 Cycle Tiller/Cultivator Specification Sheet
ENGINE DISPLACEMENT
40cc
FUEL TANK CAPACITY
0.75 L
FUEL TYPE
Minimum 87 octane gasoline with NO ethanol
content
NOTE: If using an ethanol blended fuel, a fuel
stabilizer, mixed to manufacturer specifications, is
recommended
OIL TANK CAPACITY
3.72 ounces
OIL TYPE
OIL 4 CYCLE (p/n 194211)
10W-30
SPARK PLUG
NGK CMR6A
SPARK PLUG GAP
0.6 mm
TRANSMISSION
GEAR DRIVE
GEAR RATIO
32:1
TILLING WIDTH
6” minimum - 10” maximum
TILLING DEPTH
8” maximum
TINE SPEED
288 rpm
WHEEL SIZE
7.1” x 1.5” diameter
WEIGHT OF UNIT
33 lb
UNIT SIZE L x W x H (inches)
33.6” x 17.8” x 40.6”

DR PILOT 4 Specifications

General

Brand	DR
Model	PILOT 4
Category	Tiller
Language	English
