DR PILOT 4 User Manual

24 DR
®
PILOT 2 Cycle Tiller/Cultivator
Parts List – Hood and Tines Assembly
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 26123 Tine Shield
2 26119 Transmission Assembly
3 26115 Tine -C- Assembly
4 26117 Tine -D- Assembly
5 26128 Hairpin 5/8-3/4
6 26116 Tine -B- Assembly
7 26114 Tine -A- Assembly
8 26129 Wheel Holder
9 26113 Drag Stake
10 26130 Tube Wheel Axle
11 35929 Wheel 180 X 38mm Diamond Tread Grey Hub
12 26134 Bolt M10 X 1.5 X 225 Mm
13 26131 Tube Wheel Guide
14 26132 Tube Wheel Lock
15 26133 Spring Wheel Lock
16 26120 Bolt M6 X 1.0 X 20
17 26127 Nut M6 X 1.0
18 26122 Pin Quick-Release M8 X 25
19 26124 Bolt M6 X 1.0 X 42 Flange
20 35930 Washer 21mm X 16mm X 1mm
21 35931 Lower Handlebar
22 26143 Bolt M8 X 1.25 X 160mm
23 35932 Nut M8 Nylock
24 26146 Curved Washer M8
25 39975 Engine, DR, 40cc 4 Cycle Ohv
26 35934 Nut M10 X 1.5
27 35935 Bolt M5 X 0.8 X 10
28 35978 Nut M5 X 0.8 Toplck
29 26112 Flat Washer M10 X 20 X 2
