24 DR
®
PILOT 2 Cycle Tiller/Cultivator
Parts List – Engine Assembly
NOTE:
Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 39995 Bolt M5 X 0.8 X 16 Mm W/Washer
2 39996 Air Filter Cover
3 39997 Kit Air Filter Elements
4 39974 Lock Nut M5 X 0.8 Mm Flange
5 39998 Air Filter Kit
6 39999 Hose Clamp Crankcase
7 40000 Breather Hoses Kit
8 40001 Carburetor Kit
9 40002 Carburetor Gasket
10 40003 Carburetor Insulator Kit
11 40004 Hose Clamp Valve Cover
12 40005 Ignition Coil Kit
13 40006 Bolt M4 X 0.7 X 20 Mm W/Washer
14 40007 Spark Plug Ngk Cmr6a
15 40008 Bolt M5 X 0.8 X 12 Mm W/Washer
16 40009 Engine Shroud Kit
17 40010 Shroud Cap Spark Plug Access
18 40011 Screw 3/16 X 1/2 In Phillips
19 40012 Clip Nut 3/16 In
20 40013 Valve Cover Kit
21 40014 Gasket Valve Cover
22 40015 Recoil Clutch
Ref# Part# Description
23 40016 Recoil Assembly
24 40017 Oil Cap With O-Ring
25 40018 Heat Shield Muffler
26 40019 Muffler Kit
27 40020 Bolt M5 X 0.8 X 50 Mm Socket
28 40021 Washer M6 X 10 X 1 Mm
29 40022 Bolt M6 X 1.0 X 10 Socket
30 40023 Gas Cap Self Venting
31 40024 Rubber Gas Tank Holder Top
32 40025 Rubber Gas Tank Holder Left
33 40026 Rubber Gas Tank Holder Right
34 40027 Gas Tank Kit
35 40028 Fuel Filter Aluminum Core
36 40029 Fuel Lines Kit
37 40030 Flywheel
38 39959 Lock Nut M8 X 1.25 Flange
39 39961 Washer 15.8 X 8.4 X 1.6 Mm
40 39962 Clutch Kit
41 39963 Wave Washer 10 X 15 X 0.25 Mm
42 39964 Bolt M8 X 1.25 X 25mm Shoulder
43 40031 Mount Ring And Shroud
