DR PILOT 4 User Manual

24 DR
®
PILOT 2 Cycle Tiller/Cultivator
Parts List - Transmission Assembly
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 39908 Transmission Assembly
2 26121 Dust Cap
3 26118 Fiber Washer
4 39909 Tine Shaft Seal
5* 39910 Transmission Casting Left
6 26127 Nut M6 Nylock
7 39911 Washer M6 X 12 X 1 Mm
8 26104 Wheel & Drag Stake Mount
9 39912 Bolt M6 X 1.0 X 25 Hex Flange
10 39913 Tine Shaft Bushing Steel
11 39914 Tine Shaft Shim
12 39915 Gear And Tine Shaft Assy
13 39916 Bushing Spacer
14 39917 Drive Shaft Bushing Bronze
15 39918 Drive Shaft
16 39919 Thrust Bearing Reducer
17 39920 Thrust Washer
18 39921 Thrust Bearing Cage
19 39922 Ball Bearing 9 X 26 X 8 Mm
20 25737 Clutch Drum
21 39923 Jam Nut M8
22* 39924 Transmission Casting Right
23 39925 Bolt M6 X 1.0 X 18 Hex Flange
24 39926 Bolt M6 X 1.0 X 8 Phillips
25 39927 Kit Thrust Bearing Set
* Purchase Transmission Assembly 39908
