CONTACT US AT www.DRPower.com 23
Chapter 6: Parts Lists, Schematic Diagrams and Warranty
Parts List - Main Assembly
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 A0005707744 DR Tiller Tine Drive Assembly
2 231210 Chassis - LH - TPT
3 231220 Chassis - RH - TPT
4 111491 Bolt-HCS, 1/4-20 X 1 Gr5 ZP
5 233040 Nut-Flang Hex 1/4-20 Center Lock
6 A0005506408 ASS’Y-Hitch Bracket W/Tow Bar
7 111581 Bolt-HCS, 5/16-18 X 1 Gr5 ZP
8 110761 Nut-Lock Nylon 5/16-18
9 A0005247305 Cover-Drive TPT Premier
10 231330 Bracket - Idler Arm - TPT
11 236170 Switch-Interlock TPT
12 118731 Nut-Lock Nylon 10-24
13 114781 Screw-Panhead 10-24 X 5/8 In
14 276611 Pulley - Flat Idler - 2-3/4 Dia
15 123341 Bolt-HCS 3/8-16 X 1-3/4 Gr5 ZP
16 110751 Nut-Lock Nylon 3/8-16
17 330090 Rod, Clutch TPT
18 A0005511762 Fender W/Labels-Premier 36T Tiller
19 A0005512305 Engine W/Labels-Dr 6.6hp 223cc E/S
R225
20 233110 Rod V-Belt Guide
21 112411 Washer-Flat 5/16 USS
22 A0000585488 Label, DR Logo Red 4.5in
23 233160 Nut Hex 5/16-18 Flanged Loc
24 224511 Label-Guards & Shields Warning
25 232660 Clutch Lever TPT
26 337871 Pin - Cotter Hair - 1/4 - 3/8
27 134431 Bolt-HCS5/16-18 X 1-1/2 Gr5 ZP
28 112381 Washer-Flat 1/4 USS
29 330150 Anchor TPT Premier
30 337251 Key Square 3/16 X 1.75 Wh1
31 G061342 Screw HHC, 1/2-13 X 1-1/4 G5
32 120171 Screw-Set 5/16-18 X 5/16 In
33 233570 Pulley, 8" Od
34 371691 Key - Ansi #605 Woodruff - 3/16 X 5/8
35 111241 Ring-Retaining 5/8˝
36 114431 Belt 4l450 12 In X 45 In
37 232720 Extension Spring
38 A0005506409 Cover-Belt W/Labels-36T Tiller
39 311161 Bolt-HWH 5/16-18 X .75 Taptite ZP
40 376460 Assy – Safe Start Module
41 MGHDW008 8" Zip Tie with Hole
42 A0001497252 Label-Operating Premier/Pro 36T Tiller
43 110731 Nut-Lock Nylon 1/4-20
44 G063480 Nut, Hex, Nylock 8-32
45 A0000567495 Label-Premier 36t
46 G022287 Screw HHC, 1/4-20 X 3/4 G5
47 G036919 Screw PPHM, #8-32 X 5/8
48 376580 Bracket Hitch Ext TPT 9.5 Pro
49 A0005247660 Pin-Bent Arm 1/2 X 3
Ref# Part# Description
50 160031 Pin-Hitch Clip 1/2-9/16
51 224521 Label-Tines Warning
52 110721 Nut-Nylon Lock 1/2-13
53 376590 Plate - Guard Mounting - TPT
54 G050190 Washer Flat .344id X 1.0od
55 330100 Grip-7/16" Id X 2.75 Lg
56 233060 Bolt-HCS, 5/16-24 X 1˝ W/Lock
Patch
57 179121 Bolt-Tri 1/4-20 X 1/2
58 323820 Spacer-Shoulder-Idler
59 111521 Bolt, HCS, 3/8-16 X 1 Gr5 ZP
60 A0005214640 Arm-Lift Handle
61 234191 Pin, Hair Cotter 1/8 X 1-5/8
62 231280 Cap Fender End Lg TPT
63 G024426 Screw, HHC 1/2-13 X 1-3/4 G5
64 330190 Bracket, Wheel Weight Support
65 330210 Strap-Extension Brace
66 112391 Washer-Flat 3/8 USS
67 330140 Wheel-10" X 2.25
68 223130 Pivot Axle Assy, Tow Behind Tiller
69 330160 Strap-Frame Extension
70 A0000057791 Bolt-5/8-11 X 7in-Hex-Zp
71 101311 Nut-Nylon Lock 5/8-11
72 330180 Stake, Drag TPT Premier
73 231350 Footguard Tiller TPT
74 330170 Pin-Clevis .5 X 1.5 ZP
75 330620 Spacer, .532id X .750od X 2.1l
76 231270 Cap, Fender End Rh TPT
77 330580 Bolt-Hex 1/2-13 X 5-1/2 Gr5
78 376470 Bolt Hex 3/8-16 X 2 Ft Gr2
79 G045900 Washer Flat 3/4 Zinc
80 0D4999 Pin, Cotter 1/8 X 1-1/4 ZP
81 119851 Bolt - HCS - 3/8-16 X 1 1/2 - Gr5 ZP
82 330250 Anchor - Adjustment TPT Premier
83 330060 Nut, Hex 1/2-20 Jam
84 330050 Nut-Jam-Nylon Lock 1/2-20
85 330240 Rod - Lift TPT Premier
86 234991 Washer, 0.53 Id X 1.06 Od X 0.095 -
ZP
87 330070 Spring-Depth Extension
88 126861 Bolt, HCS, 3/8-16 X 2 Gr5 ZP
89 126831 Nut, Finish, 3/8-16
90 330250 Anchor - Adjustment TPT Premier
91 365211 Bolt-Hex Flange 1/4-20 X 5/8 ZP
92 110701 Nut - Finish - 1/4-20 - ZP
93 187621 Bolt Carriage 5/16-18 X1 Gr5 ZP
94 330081 ASS’Y-Lift Handle Premier
95 330610 Washer-.406id X 1.187od X .187
96 330600 Spacer-.406id X .550od X .62
97 330040 Pulley-4.5" Od Tiller
To Next Page
