8 DR
®
TOW-BEHIND ROTOTILLER
DR TOW-BEHIND ROTOTILLER Specification Sheet
Assembling the Machine
NOTE: Assembling the DR TOW-BEHIND ROTOTILLER is a two-person job, as the Unit weighs 169 pounds. We recommend you have
an extra set of hands available before you begin.
Parts Supplied on Shipping Pallet:
• DR TOW-BEHIND ROTOTILLER
• Wheel Box:
- Two Wheels
- Hitch Bracket Extension
- Bolt, 1/2˝ x 1-1/4˝
- Locknut, 1/2˝-13
- Safety & Operating Instructions Manual
- DR Engine Manual
Tools and Supplies Needed:
• Pliers
• 1/2 Wrench
• (2) 9/16 Wrenches
Engine
DR 6.6HP, 223 CC, Single Cylinder
Approximate Run Time on a Tank of Fuel
90 minutes
Towing type
Pin Hitch
Ground Clearance in Transport Mode
1.5"
Height Adjustment
Manual
Range
5.5" deep
Tine Size
12"
Number of Tines
12
Wheels
10" x 2.25" Polypropylene
Machine Size
39"w x 66"L (Transport), 35"H x 77"L (Lowest Position)
Machine Weight
169 lbs
Tongue Weight
90 lbs. (Transport) 112 lbs. (Lowest Position)
Shipping Weight
310 lbs.
Gauge of Steel on Shroud
13
Gauge of Steel on Frame
12 Gauge, 1.5" Tubular Steel
