Removing the Wheels
Tools needed:
• Needle Nose Pliers
1. Block the machine so the Wheel you are removing is off the ground.
2. Remove the Retaining Ring with the Pliers.
3. Remove the Shim and slide the Wheel off the Axle (Figure 16).
4. Replace the Wheel in the reverse order as above.
NOTE: Make sure the Retaining Ring in fully locked onto the Axle when installing
Wheels.
Retaining Ring
and Shim
Figure 16
Wheel
