FIELD AND BRUSH MOWER
Chapter 6: Parts Lists, Schematic Diagrams And Warranty
Parts List - HANDLEBAR ASSEMBLY
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 165201 Switch, Snap-in m/s
2 157201 Key, Ignition Switch
3 191231 Switch, Push/pull TPDT
4 150491 Screw, 8-32 x 1/2"
5 110971 Pin, Spring, 3/16" x 1-3/4"
6 247371 Arm, Shift Upper
7 110221 Grip, Shift Handle
8 134431 Bolt, HCS, 5/16-18 x 1.5", GR5
9 247301 Handlebar, Right
10 164961 Grip, Plain, 1"
11 111521 Bolt, HCS, 3/8-16 x 1", GR5
12 110761 Nut, Nylon Lock, 5/16-18
13 139051 Cable, Throttle, 50"
14 247291 Handlebar, Left
15 179231 Screw, SH, M6 25mm
Ref# Part# Description
16 164971 Guard, Switch Magura
17 181731 Lever, OP w/Harness
18 164951 Grip, Ergonomic, 1"
19 165171 Lever, Wheel Clutch
20 247431 Cable, Traction Drive
21 110751 Nut, Nylon Lock, 3/8-16
22 114681 Bolt, HCS, 1/4-20 x 1-1/4", GR5
23 110731 Nut, Nylon Lock, 1/4-20
24 247361 Arm, Shift Lower
25 256411 Wire Harness, 12.5 B&S
26 257041 Panel, Control, w/ Labels
27 256891 Label, DR Strip
28 256901 Label, Throttle
29 256881 Label, Control Panel
