24 PREMIER DR
®
FIELD AND BRUSH MOWER
Parts List – TRANSAXLE AND WHEEL ASSEMBLY
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 110761 Nut, Nylon Lock, 5/16-18
2 112411 Washer
3 247421 Guide, Belt
4 150691 Bolt, HCS Shoulder, 3/8-16 x 2-1/2
5 123211 Bolt, HCS, 5/16-18 x 3/4, Gr5, zp
6 110751 Nut, Nylon Lock, 3/8-16
7 123341 Bolt, HCS FT, 3/8-16 x 4-1/2, Gr5, zp
8 112391 Washer, Flat, 3/8 USS
9 113071 Bolt, HCS FT, 3/8-16 x 4-1/2, Gr5, zp
10 247391 Arm, Idler
11 151111 Bushing, .39ID x .62OD x 1.585
12 111241 Ring Retaining 5/8 SH
13 111141 Pulley, V-Belt, 7", 5/8" Bore
14 150061 Belt A31K 1/2 x 33
15 123361 Bolt, HCS, 5/16-18 x 1-1/4, Gr5, zp
Ref# Part# Description
16 247361 Arm, Shift, Lower
17 247381 Linkage, Shift
18 111501 Screw, Socket HD, 1/4-28 x 3/4, blk
19 112481 Washer, Lock, 1/4
20 112381 Washer, Flat, ¼, USS
21 247401 Arm, Shift
22 247411 Bracket, Transaxle
23 144701 Bolt, HCS, 5/16-18 x 3/4, serrtd flang
24 111261 Ring, Retaining, 3/4, E
25 129691 Shim, .75ID x 1.125OD x .06L, zp
26 247441 Wheel, 14.5 x 7-6, 2 Ply, Gray
27 247461 Transaxle, 3 Speed
28 247271 Frame, Rear
29 120301 Screw, Tri 3/8-16 x 1-1/2
