26 PREMIER DR
®
FIELD AND BRUSH MOWER
Parts List – BRUSH DECK ASSEMBLY
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 257051 Cover, Deck, w/ Labels
2 143661 Knob, handlebar, 5/16-18
3 110751 Nut, Nylon Lock, 3/8-16
4 101621 Spring, E, .750OD, .105wire, 5.0L, zp
5 112391 Washer, Flat, 3/8, USS
6 150611 Arm, Idler, Traction Drive
7 247451 Bushing, Idler
8 180121 Pulley, Flat Idler, 3.25
9 179261 Bolt, 3/8-16 x 3-1/2, Full, Gr5
10 123211 Bolt, HCS, 5/16-18 x 3/4, Gr5, zp
11 110761 Nut, Nylon Lock, 5/16-18
12 257061 Deck, 24", w/ Labels
13 129601 Bolt, HCS, 3/8-16 x 3, Gr5, zp
14 246771 Key, Square, 3/16" x 1"
15 139031 Blade, Brush, 24"
16 101771 Washer, .640 ID x 2-1/2 OD
17 175451 Bolt, HCS, 5/8-11 x 1-1/4
Ref# Part# Description
18 256391 Housing, Spindle
19 112381 Washer, Flat, 1/4, USS
20 150451 Bolt, HCS, 5/16-18 x 1-3/4, Gr5, zp
21 109481 Cap, Round, 1"
22 123361 Bolt, HCS, 5/16-18 x 1-1/4, Gr5, zp
23 257071 Frame, Front, W/ Labels
24 123211 Bolt, HCS, 5/16-18 x 3/4, Gr5, zp
25 256421 V-Belt
26 112431 Washer, Lock, 5/16"
27 136491 Label, Danger
28 148231 Label, Safety Icons
29 164371 Label, Brush Belt Guide, 5" x 3"
30 124371 Label, American Flag
31 240531 Label, 4" DR Logo, Silver
32 247321 Pulley, 6-1/2"
33 247351 Bar, Brush
34 212581 Washer, Slit Lock, 5/8", GR8
