Connecting the DR SELF-FEEDING WOOD CHIPPER to your
Tractor – Yard-Tow Models
1. Lift the Chipper Tow Bar onto the Tractor Hitch and install the Hitch Pin
and Hitch Clip to secure it (Figure 28).
2. Pull the Hitch Clip from the Pin and pull the Pin from the Support Leg and
Tow Bar (Figure 29).
3. Rotate the Support Leg to the up (transport) position, align the holes in the
Tow Bar and Leg, reinstall the Pin and secure with the Hitch Clip (Figure
30).
Connecting the DR SELF-FEEDING WOOD CHIPPER to your
Vehicle – Road-Tow Models
1. Pull the latch assembly on the Tow Hitch Assembly up and into the open
position. Position the hitch coupler of the Chipper over and onto the tow
vehicle’s tow ball (must be a 2" tow ball) (Figure 31).
2. Pull the Hitch Clip from the Pin and pull the Pin from the Support Leg and
Tow Bar (Figure 29).
3. Rotate the Support Leg to the up (transport) position, align the holes in the
Tow Bar and Leg, reinstall the Pin and secure with the Hitch Clip (Figure
30).
4. Close the Latch Assembly on the Tow Hitch Assembly to lock it onto the
Tow Ball (Figure 32). Attach the towing Safety Chains to the tow vehicle
ensuring there is enough slack for turning.
5. Insert the Locking Pin into the hole in the Latch Assembly.
