DR Pro 475 - Chapter 6: Parts Lists and Schematics; Drive Assembly Parts and Schematic

40 DR
®
SELF-FEEDING WOOD CHIPPER
Chapter 6: Parts List and Schematic Diagrams
Parts List – Drive Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 164521 Key, 1/4 Square X 2 in
2 10000046073 Engine, B&S, 16.5 GTQ, M/S (Pro)
10000046094 Engine, B&S, 16.5 GTQ, E/S (Pro)
10000046103 Engine, B&S, 21.0 GTQ, E/S (Pro-
XL)
3 123341 Bolt, HCS, 3/8-16 x 1-3/4, Gr5
4 112391 Washer, Flat, 3/8
5 110751 Nut, Nylon Lock, 3/8-16
6 10000030715 Bracket, Belt Tensioner
7 112411 Washer, Flat, 5/16"
8 110761 Nut, Nylon Lock, 5/16-18
9 142321 Key, Square, 1/4" X 1"L (Pro)
A0000080596 Key, 0.25 X 0.184 X 1.25 (Pro-XL)
10 10000043566 Clutch, Centrifugal 1 in Bore 1800
RPM, 3 Spring (Pro)
10000043555 Clutch, Centrifugal, 1 in Bore 1800
RPM, 2V (Pro-XL)
11 191301 Washer, Flat, .469" ID x 1.62" OD
.25" L, GR5
12 222521 Washer, Lock, 7/16, Split
13 396111 Bolt, HCS, 7/16-20 X 1-3/4", GR8,
ZP
14 10000043816 Belt, 5L550, (Pro)
10000043806 Belt, 5L640, (Pro-XL)
15 10000043860 Pulley, 5L 5.95 OD X 1.25 Bore
(Pro)
10000043851 Sheave Pulley, 5L 5.95 OD 2
Groove QD H (Pro-XL)
16 10000043480 Belt Guard (Pro)
10000043438 Belt Guard (Pro-XL)
17 10000043466 Bracket, Belt Guard
18 10000043845 Sheave Bushing-QD H 1.25 Bore
(Pro-XL)
19 10000043436 Bracket, Belt Guard, Lower (Pro-XL)
20 123211 Bolt, HCS, 5/16-18 x 3/4"
Ref# Part# Description
21 386571 Spacer, 0.73" Inch Long (Pro)
22 10000037755 Bolt, Hex, 5/16-18 X 2-1/2", Tri, Ft
23 111521 Bolt, HCS, 3/8-16 x 1, Gr5
24 189801 Bolt, HCS, 5/16-18 x 4-1/2, Gr5
25 10000043407 Discharge Weldment (Pro)
10000043460 Discharge Weldment (Pro-XL)
26 104831 Battery, SLA 12V 17AH (Electric
Start)
27 10000043546 Strap, Battery, Rod (Electric Start)
28 112381 Washer, Flat, 1/4", SAE (Electric
Start)
29 110731 Nut, Nylon Lock, 1/4-20 (Electric
Start)
30 10000046092 Spacer-1.265 ID X 1.75 X .062 (Pro)
31 10000043521 Arm, Bolt On, LH (Pro)
10000043511 Arm, Bolt On, LH (Pro-XL)
32 10000043512 Arm, Bolt On, RH (Pro)
10000043445 Arm, Bolt On, RH (Pro-XL)
33 178821 Bolt, HCS, 5/16-24 X 1", GR2, ZP
34 10000043543 Guard, Inner Belt (Pro)
10000043524 Guard, Inner Belt (Pro-XL)
35 10000045522 Washer, .344 ID X 1.62 X .25 (Pro)
36 28697 Pad, Battery 2.5 x 6.125 (Electric
Start)
37 A0000181535 Spacer, 1.25" ID X 0.73" Inch Long
(Pro)
Not Shown
10000046251 Wire, Ground 26 in (Electric Start)
10000046229 Wire, Positive 26 in (Electric Start)
137581 Label, Check Oil
10000042667 Label, Danger, Chipper/Trimmer
10000042639 Label, Warning Chipper/Trimmer
188871 Label, Hot
10000037322 Decal, Prop 65
