DR Pro 475 - Chipper Basic Assembly Parts and Schematic

42 DR
®
SELF-FEEDING WOOD CHIPPER
Parts List - Chipper Basic Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 10000043425 Sideplate, Hopper (Pro)
10000043426 Sideplate, Hopper (Pro-XL)
2 10000043428 Scroll (Pro)
10000043369 Scroll (Pro-XL)
3 10000043408 Sideplate, Vent (Pro)
10000043462 Sideplate, Vent (Pro-XL)
4 189801 Bolt, HCS, 5/16-18 x 4-1/2, Gr5
5 110761 Nut, Lock, 5/16-18
6 10000043464 Scroll Tube (Pro)
10000043465 Scroll Tube (Pro-XL)
7 10000030955 Flywheel, Balanced w/Knife (Pro)
10000030956 Flywheel, Balanced w/ Knife (Pro-
XL)
8 10000043547 Bearing, Flange, 1-1/4" Shaft
9 10000046092 Spacer-1.265 ID X 1.75 X .062
10 10000043548 Ring, Retaining, 1-1/4 Shaft
11 229091 Bolt, HCS, 1/2-13 x 1-1/2, Gr5
Ref# Part# Description
12 110721 Nut, Lock, 1/2-13, Gripco
13 10000043471 Plate, Wear (Pro)
10000043453 Plate, Wear (Pro-XL)
14 157471 Bolt, Carriage, 1/4-20 x 1
15 112381 Washer, Flat, 1/4", SAE
16 110731 Nut, Nylon Lock, 1/4-20
17 10000043452 Plate, Access 3 Hole (Pro)
10000043409 Plate, Access 3 Hole (Pro-XL)
18 10000043472 Plate, Access, 2 Hole (Pro)
10000043385 Plate-Access, 2 Hole (Pro-XL)
19 380491 Knife Kit, (Pro)
380501 Knife Kit, (Pro XL)
Not Shown
10000043344 Label, DR Logo 5.75 Matte
10000042683 Label, Warning Rotating Blade
197091 Gauge, Knife Gap
