36 DR
®
PRO XL520 CHIPPER SHREDDER
Parts List –Frame and Drive Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 A0001609606 Engine, DR 12.0 HP, 420cc E/S,
w/Labels
2 10000043555 Clutch, Centrifugal, 1" Bore, 1800
Rpm, 2V
3 104831 Battery, 17Ah, 12V
4 10000041723 Guard, Belt
5 10000041732 Bracket, Belt Guard, Engine Mount
6 10000041927 Bracket, Oil Drain
7 10000030715 Bracket, Belt Tensioner
8 10000042000 Belt, V-B64, Corded, Raw Edge
9 286971 Pad, Battery, 2.5" X 6.125", Stg
10 A0000069779 Wire, Positive, 30"
11 A0000069783 Wire, Ground, 12"
12 124511 Clamp, Battery
13 294871 Boot, Rubber, Red
14 111701 Screw, 10-32 X 1/2", Type F
15 373401 Clamp, Cable, 3/8", Nylon Black
16 A0000268958 Frame, Base w/Labels
17 252971 Wheel and Tire Assembly
18 10000041386 Frame, Axle
19 10000043447 Leg, Support, Road Tow
20 10000043477 Plate, Hitch, Bent
21 A0000267433 Frame, Tow Bar w/ Labels
22 110731 Nut, Nylon Lock, 1/4-20
23 110751 Nut, Nylon Lock, 3/8-16
Ref# Part# Description
24 110761 Nut, Nylon Lock, 5/16-18
25 111411 Bolt, HCS, 5/16-18 X 3", GR5, ZP
26 111521 Bolt, HCS, 3/8-16 X 1", GR5 ZP
27 121701 Washer, Flat, 3/8", SAE
28 10000037755 Bolt, Hex, 5/16-18 X 2-1/2", TRI FT
29 129601 Bolt, HCS, 3/8-16 X 3", GR5, ZP
30 160031 Pin, Hitch Clip, 1/2"-9/16"
31 187371 Pin, Clevis, 1/2" X 4.5" L, ZP
32 189671 Washer, Rubber, 1/2" ID 1" OD
33 112381 Washer, Flat, 1/4", USS
34 253101 Nut, Castle, 1-14
35 253111 Pin, Cotter, 5/32" X 2", ZP
36 228871 Washer, .385″ ID X 1.5″ OD X .25″L
37 323971 Pin, Hitch, 3/8" X 3", W/Cotter Pin
38 157301 Bolt, HCS, 1/4-20 X 3/4", GR5, ZP
39 351681 Bolt, HHCS, M8-1.25 X 20, Class 8.8,
ZP
40 250441 Label, Warning, Pinch Point, 3.5" X 1"
41 137581 Label, Check Oil, 2.75" X .63"
42 188871 Label, Hot Surface, R/C
43 10000036023 Decal, Prop 65 Short Form
44 10000043333 Label, Warning, Tow Max 10mph
45 144450 Bolt, HCS, 3/8-24 X 1-1/2″, GR8, YZP
