CONTACT US AT www.DRpower.com 13
Chapter 3: Operating the DR FIELD and BRUSH MOWER
You may find it helpful to review the DR FIELD and BRUSH MOWER Controls
and Features in Figure 2a (page 7) or Figure 2b (page 8) before reading this
chapter.
Before Starting the Engine
Check the Engine Oil level every time before you use the machine.
Check the gas level.
Ensure that the Fuel Shut-Off Valve located under the Fuel Tank is open
(Figure 15a XD30 Machines or Figure 15b XD26 machines).
Ensure the Blade Engage Lever is disengaged.
Starting
XD 30 with Kawasaki Engine
1. Move the Throttle Lever to Choke (to Fast if the Engine is already
warm) (Figure 16).
2. Rotate Key to the Start position until the Engine starts, then release.
The Key will return to the Run position and the Engine will continue to
run.
3. Move the Throttle Lever to the Fast position.
XD 26 with Honda Engine
1. Pull out the Choke Lever located on the back of the Engine (leave Choke
pushed in if the Engine is already warm) (Figure 17).
2. Move the Throttle to Fast Position (Figure 16).
3. Grasp the Recoil Starter Handle and slowly pull until you feel resistance. Let
the Cord retract a little bit, and then pull the Cord rapidly to start the Engine.
4. When the Engine starts, push the Choke Lever all the way in. (Figure 17).
Stopping the Engine
XD 30 with Kawasaki Engine
1. Ensure the Blade Engage Lever is Disengaged (Figure 16).
2. Move the Throttle Control Lever to the IDLE position.
3. Turn the Key to the Stop position and remove it for safety.
Note: Close the Fuel Shut-Off Valve when transporting or storing the Mower
(Figure 15a).
