40 DR
®
FIELD and BRUSH MOWER
Parts List – Brush Deck Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 187621 Bolt, Carriage, 5/16-18 X 1″, GR5, ZP
2 393541 Bolt, Hex, Flange, 5/16-18 X 1.00″,
GR5, ZP
3 110691 Nut, Finish, 5/16-18, ZP
4 151381 Washer, 1.375″ ID, 2.0″ OD
5 A0000253469 Washer, 1.38″ ID, 2.0″ OD .5L
6 150461 Pin, Detent, 1/4″ X 2″
7 A0000647158 Cover, Belt
8 A0002045835 Brush Deck, 26″, w/Labels (XD26)
A0002045827 Brush Deck, 30″, w/Labels (XD30)
9 100491 Blade, Brush, Heavy Duty, 26″ (XD26)
166311 Blade, Brush, Heavy Duty, 30″ (XD30)
10 A0000647273 Spindle Assembly
11 A0000648419 Brush Bar, 26″ (XD26)
A0000966706 Brush Bar, Solid, 30″ (XD30)
12 333521 Bolt, Hex, Flange, 5/16-18 X 1.5″
13 333321 Nut, Nylon Lock, Flanged, 5/16-18
14 101771 Washer, .640″ ID X 2-1/2″ OD
15 160071 Nut, Nylon Lock, 5/8-18, GR2, ZP
16 151271 Pulley, Flat Idler, 4″
Ref# Part# Description
17 A0000648427 Idler, Brush Deck
18 350511 Spacer, Idler
19 352811 Bolt, Hex, Flange, TL, 3/8-16 X 3/4″
20 333331 Nut, Nylon Lock, Flanged, 3/8-16
21 150941 Spring, E, .750″OD .112Wire 5.0L
22 333481 Bolt, Hex, Flange, 3/8-16 X 2.5″
23 A0000332299 Grease Zerk, Straight, 1/4-28
24 164451 Pulley, V-Belt, 8-1/2″, 7G
25 150721 Bushing, 1.38″ ID, 1.63″OD, 1.5L
26 136491 Label, Danger
27 10000031856 Skirt, Front, Rubber, 26″ (XD26)
10000031814 Skirt, Front, Rubber, 30″ (XD30)
28 366161 Strap, Skirt Mounting, 26″ (XD26)
366151 Strap, Skirt Mounting, 30″ (XD30)
29 345171 Bolt, Hex, Flange, 3/8-16 X 3.5″
30 A0000648432 Guard, Rear, 26″ Deck (XD26)
A0000648433 Guard, Rear, 30″ Deck (XD30)
31 A0000253559 Plate, Stud Guard
32 A0000910019 Guard, Anti Wrap
