Page | 13
BiliLux LED Phototherapy Light
Checking Irradiance with the (optional) Radiometer
o Ensure that the radiometer is connected to the receptacle on the
rear of the phototherapy light
1.
Press the key until the Radiometer screen is displayed.
To obtain the irradiance measurement.
o Position the radiometer sensor close to the patient’s skin, without
touching the patient.
1
Radiometer Screen Displays
1. The Radiometer screen displays the current irradiance measurement
in units of μW/cm2/nm and allows the user to store the measurement.
2. Date, time, and irradiance value of the previously stored
measurement
3. To store the current irradiance measurement, press
Store
button on
the radiometer or the
Store
button (C) on the radiometer screen.
The
Last stored :
information (B) at the bottom of the screen is
updated accordingly.
1
2
3
