14 Quick installation guide | Dräger Interlock

7500

| Description

Legend

1 Holster for handset

2 Air outlet

3 Down/Menu button

4 OK button

5 Mouthpiece

6 Expansion box connection (optional)

7 GPRS module connection (optional)

8 Control unit

9 Bushing for plug connector on spiral cable

10 Camera connection

11 IR interface

12 Spiral cable

13 Bushing for plug connector on spiral cable
