4 Installation
NOTICE
Only install the device permanently following consultation with the owner of the
vehicle.
When installing the control unit, ensure that the connection cable for the
handset is secured against tensile load (e.g. using a cable tie).
Cable colours:
Grey/brown (PIN 1 and 2): floating switching output for clearance to start (e.g.
terminal 50)
Blue (PIN 4): Terminal 15
Black (PIN 5): Terminal 31
Red (PIN 6): Terminal 30
4.1 Requirements for installation
WARNING
Danger!
Alterations and additions to the device may cause danger.
Such alterations and additions invalidate the certificate of installation contained
in the instructions for use.
► There may be no alterations or additions made to the device.
NOTICE
Install the device only for interruption and connection to the starter relay control
line.
4.2 Installation mode
CAUTION
The device is supplied in an installation mode, depending on configuration. In
this mode, the device immobilizer is not yet enabled. The vehicle's engine can
be started after the unit is installed without a breath sample being given.
Deactivate this mode when commissioning the device.
4.3 Connecting the leads
NOTICE
Check for any installation instructions specific to the vehicle, and if these exist,
continue by following those instructions. A list of available installation
instructions can be obtained from Dräger.
NOTICE
Ensure that all control unit cables, as well as newly established electrical
connections to the vehicle, are firmly attached and are not exposed to any
tensile stress following installation.
Dräger recommends bundling the control unit cables, e.g. with duct tape, to
ensure they do not hang loose and thus preventing any manipulation.
NOTICE
Disconnecting the vehicle battery may erase battery-dependent device settings
(e.g. the theft code for the radio or the preset stations). On some vehicles,
disconnecting the vehicle battery may turn the airbag light on, which can then
only be turned off by the vehicle manufacturer.
