Dräger Interlock 7500 Quick Installation Guide

Installation |
Quick installation guide | Dräger Interlock
®
7500 17
CAUTION
Fire hazard!
► Ensure there is a clean and reliable connection between the leads!
CAUTION
Do not trim the leads of the vehicle so that they can be used again after
deinstallation of the control unit.
CAUTION
If "Start recognition type 3 (light machine)" is selected, connect the AUX 3 input
(PIN 16) of the control unit with the output of the light machine (D+ lead)!
WARNING
Do not install holster for handset in front of airbags.
NOTICE
The Dräger thermo-shrinkable tubing means that any future change or
manipulation of the joint can be detected.
NOTICE
Some vehicles have positive wires whose current is switched off some time
after the vehicle is locked. Always use a positive wire which is constantly under
voltage, as otherwise the buffer battery in the control unit will be drained.
